Silicone Rubber Cable
Silicone rubber insulated flexible cable for equipment operating in extreme heat or sub-zero cold.
180°C ratedHalogen-freeIS 6380
Voltage450/750 V
Temperature-55°C to 180°C continuous / 350°C short-circuit
StandardIS 6380 (Type IE5)
Technical Specifications
| Construction | |
| Conductor | Annealed tinned copper, flexible stranded, Class 5 (IS 8130) |
| Conductor size range | 0.5 – 120 sq.mm |
| Number of cores/pairs | Single core (multicore on request) |
| Insulation | Silicone Rubber – Type IE5 (IS 6380) |
| Inner sheath | N/A (multicore: extruded silicone bedding) |
| Shielding/screen | N/A (screened version on request) |
| Armour | Unarmoured |
| Outer sheath | Silicone rubber / glass-fibre braid (on request) |
| Ratings & Standards | |
| Voltage grade | 450/750 V |
| Temperature rating | -55°C to 180°C continuous / 350°C short-circuit |
| Applicable standards | IS 6380 (Type IE5), IS 8130, BS 6899 |
| Special properties | Withstands extreme heat & cold without embrittlement; flexible, flame & ozone resistant, halogen-free |
Applications
Furnace, oven & industrial heating equipment
High-temperature lighting fixture wiring
Equipment exposed to extreme thermal cycling
Foundry & steel plant equipment wiring
