Fire Alarm Cable
Low smoke cable for fire detection and alarm circuits requiring dependable signalling.
LSZHBS 6387Fire-resistant option
Voltage300/500 V
Temperature70°C continuous
StandardIS 694
Technical Specifications
| Construction | |
| Conductor | Solid / stranded copper |
| Conductor size range | 1.5 sq.mm typical (0.5–2.5 sq.mm range) |
| Number of cores/pairs | 2, 3, 4 core |
| Insulation | PVC / LSZH |
| Inner sheath | Extruded bedding (multicore) |
| Shielding/screen | Overall Al-Mylar + drain wire (optional) |
| Armour | Unarmoured (armoured on request) |
| Outer sheath | LSZH (red jacket convention) |
| Ratings & Standards | |
| Voltage grade | 300/500 V |
| Temperature rating | 70°C continuous |
| Applicable standards | IS 694, BS 5839, BS 6387 (fire resistance) |
| Special properties | Low smoke zero halogen, fire-resistant options available |
Applications
Fire detection & alarm panels
Emergency signalling circuits
Building life-safety systems
Sprinkler & suppression system control
