Copper Braided Cable
Highly flexible braided copper conductor used for bonding, grounding and shielding.
High flexibilityBonding/earthingCustom sizes
VoltageEarthing / bonding application (not power-rated)
TemperatureUp to 105°C
StandardIS 8130 (wire basis)
Technical Specifications
| Construction | |
| Conductor | Bare / tinned copper braid, fine-strand construction |
| Conductor size range | 1.5 – 300 sq.mm (braid cross-section) |
| Number of cores/pairs | Single braid (flat or round) |
| Insulation | Bare (insulated/sleeved versions on request) |
| Inner sheath | N/A |
| Shielding/screen | N/A (used as shield/bond conductor itself) |
| Armour | N/A |
| Outer sheath | Bare / PVC sleeve (on request) |
| Ratings & Standards | |
| Voltage grade | Earthing / bonding application (not power-rated) |
| Temperature rating | Up to 105°C |
| Applicable standards | IS 8130 (wire basis), custom braiding specification |
| Special properties | High flexibility, low impedance, excellent bonding conductivity |
Applications
Earthing & bonding jumpers
EMI/RFI shielding braids
Battery & busbar interconnections
Flexible grounding straps
